RMS-H
The RMS-H (Radiation Monitoring System for Hospital) is radiation detection in operating rooms and radiation isotope-labeled radio pharmaceutical manufacturing rooms and monitoring of radiation exposure conditions throughout the hospital.
When radioactive materials are detected, guidance is given to safety / caution / danger according to the amount of radiation and the current status is transmitted to the monitoring system.
Detector
Detector type |
Plastic scintillator |
Volume |
5.67 L (324 mm x 239 mm x 733 mm) |
Efficiency |
10,000 cps / (μSv/h, Cs-137), 5,000 cps / (μSv/h, Co-60) or more |
Sensitivity |
0.2 μSv/h BG condition, 0.1 μSv/h change detection ( <1 s ) |
Operating range |
40 keV ~ 3 MeV (Gamma) |
Operating temperature |
5℃ ~ 55℃ |
Alarm
Alarm type |
Radiation detection |
Alarm |
Screen flickering, Beeping, Sending mail |
System specification
Operating system |
Windows 10 S |
CPU |
Intel N4020 |
GPU |
Intel UHD600 |
RAM |
4 GB DDR4 |
Built-in memory |
64 GB + 256 GB |
Display
Screen size |
26.16cm(10.3 inch) |
Panel type |
IPS-LCD |
Resolution |
1920 x 1200 / 219ppi |
Network
Bluetooth |
v5.0 |
Other specifications
I/O port |
USB x 3 |
Speaker |
Stereo speaker |
Power / Battery
Charging terminal |
USB-C |
Usage time |
Up to 9 hours |
Size / Weight
Size |
324 x 239 x 73.3 mm |
Weight |
2825 g |
Video
